CS210 · Mobile Application Development · Fall 2026

Four demos for
lifecycle and layout.

Lecture 4 has a moment where the screen resets and nobody knows why. These four pages let the class cause that moment, then remove it — and see the view tree underneath while it happens.

Macau University of Science and Technology · Faculty of Innovation Engineering · Prof. Rui ZHAO

A mechanical stopwatch on a wooden panel
DEMO 01

Being an Activity

Press Home, Back, a dialog and a rotation. The Logcat fills with the real callbacks, and a running clock shows what each one costs you.

Hour 1 · the lifecycleOpen →
A phone showing a stopwatch stopped at zero
DEMO 02

Save and Restore the Stopwatch

Rotate with the fix off and the clock dies. Switch it on and the same rotation keeps the value — with the real Bundle contents on screen.

Hour 1 · the fixOpen →
White storage boxes nested inside one another
DEMO 03

Views and ViewGroups

Click any node of the real layout tree. See what class it is, what it inherits — and which nodes are allowed to contain children.

Hour 2 · the view treeOpen →
A grid of white boxes, one knocked out of alignment
DEMO 04

Gravity and layout_gravity

The same click on both attributes, side by side. Watch which one moves the text and which one moves the box — plus stacking with a FrameLayout.

Hour 2 · layoutOpen →

Using these in class

  • Each demo is a single self-contained page — open it directly, or press 1–4 from this index. 0 comes back here.
  • Nothing here needs the network. The whole folder works offline, projector network or not.
  • Demo 01 and Demo 02 are a pair. Do not explain the rotation away in the first one — let them watch the clock reset, then move to the second and fix it. Two minutes of “why did that happen?” is worth more than the slide.
  • Demo 03 and Demo 04 are the second half of the lecture. Both are reference tools: leave the tab open while you talk, and click through it rather than describing it.
